Your are here: Home >> Products >>HH-TGS tube-in-tube sterilizer
HH-TGS tube-in-tube sterilizer use for tomato, onion, chili, strawberry, blackberry, carrot, peach, apricot and other material after concentration’s material conducting sterilization.
Directory
- Live Demonstration of Ketchup Production Line
- Characteristics of HH-TGS tube-in-tube sterilizer
- Technical Parameters of HH-TGS tube-in-tube sterilizer
- HH-TGS tube-in-tube sterilizer Finished Picture
Live Demonstration of Ketchup Production Line
Characteristics of HH-TGS tube-in-tube sterilizer
This tube-in-tube sterilizer mainly constitute of four level’s tube-in-tube or (multi-tube) heat exchanger, infinitely variable speed pump, retainer, sealed bucket, a hot water generator, support leg, controller, etc
This equipment equipped with heating section, sterilization keep section, cooling section, tube set of simple structure, small resistance.
Material’s heating---keep section’s structure reasonable collocation, guarantee the stability of temperature, the product security.
Cleaning process contains a hot water and cooling water flow. Prevention wall scaling effect heat exchange effect. Bactericidal used hot water heating method of the pipes, to improve the thermal efficiency.
LED display operation screen, PLC system for full automatic device and used in the device of multichannel record instrument temperature record.
Technical Parameters of HH-TGS tube-in-tube sterilizer
|
Specification |
Handling capacity kg/h |
Sterilization tempera
ture ℃ |
Cooling tempera
ture ℃ |
Power consum
ption KW |
Steam evapor ation kg/h |
Water consum ption kg/h |
Compre ssed air consum ption kg/h |
Installation dimension mm |
|
HH-TGS-1 |
1000 |
110 |
32-45 |
14.1 |
150 |
5000 |
0.1 |
8000×800 ×1000 |
|
HH-TGS-2 |
2000 |
110 |
32-45 |
19.2 |
3000 |
10000 |
0.1 |
8000×1000 ×1000 |
|
HH-TGS-3 |
3000 |
110 |
32-45 |
33 |
450 |
15000 |
0.3 |
8000×1200 ×1200 |
|
HH-TGS-6 |
6000 |
110 |
32-45 |
64.5 |
900 |
42000 |
0.3 |
8000×1200 ×1800 |
|
HH-TGS-8 |
8000 |
110 |
32-45 |
80.5 |
1200 |
56000 |
0.4 |
8000×1200 ×1800 |
|
HH-TGS-10 |
10000 |
110 |
32-45 |
110 |
1500 |
70000 |
0.5 |
8000×1400 ×2000 |
|
HH-TGS-12 |
12000 |
110 |
32-45 |
132 |
1800 |
84000 |
0.5 |
8000×1400 ×2000 |
Notes: installation dimension—(can according to customer processing size flexible adjustment)
HH-TGS tube-in-tube sterilizer Finished Picture
Notice: We provide equipment suggestion, proposal design, project installation and after_sale service for liquid food turn-key projects.
